오원 ・ OWON
ODP8354
프로그래머블 DC 파워서플라이
ODP8354 Programmable DC Power Supply
- 3 or 4-channel independent adjustable output channels; CH1 and CH2 support series/parallel connection
- CH1/CH2: 5A / 90W constant power; CH3/CH4: 3A / 24W constant power
- 5-digit voltage/current display with 1mV / 1mA resolution
- Low ripple and noise: ≤1mVrms / 5mVpp
- OVP, OCP, OTP, OPP protection for safety and reliability
- Intelligent CV/CC mode switching
- Supports 100 sets of timed output sequences
- Remote voltage sensing supported
- Built-in data logger for displaying voltage, current, and power in table or waveform format
- System parameter save/recall, with expandable data storage
- 4.3-inch (480*272) IPS screen for sharp and vivid display
- Supports USB 2.0, RS232, and LAN communication interfaces
