오원 ・ OWON
ADS3202A
12비트 다기능 디지털 스토리지 오실로스코프
ADS3202A 12-BIT MULTIFUNCTION DIGITAL STORGE OSCILLOSCOPE
- All-in-one functionality: Integrates oscilloscope, dual-channel 50MHz AFG(optional), frequency counter, voltmeter, FFT spectrum analyzer, and protocol analysis.
- 100MHz–500MHz bandwidth with 2.5GSa/s real-time sampling rate.
- 100Mpts memory depth, waveform capture rate up to 500,000 wfms/s.
- 12-bit hardware ADC with 16x higher measurement accuracy than conventional oscilloscopes.
- Vertical resolution: 500μV/div–10V/div; Timebase range: 500ps/div–1000s/div.
- Advanced triggers: edge, video, pulse width, slope, runt, timeout, Nth edge, logic, RS232/UART, I²C, SPI, CAN, LIN.
- Dual-channel hardware decoding: RS232/UART, I²C, SPI, CAN, and LIN.
- Waveform cloning and bode plot analysis (AFG models).
- Convenient measurement statistics, with measurement indicators, cursor gating, and more measurement prompts.
- Built-in microphone & speaker, supports external peripherals(mouse, keyboard) to enhance interactivity.
- Equipped with HDMI, USB device1, USB Host3, Trig Out(P/F), LAN, supporting Web Control and SCPI command tools.
- Optional wireless module (Wi-Fi/Bluetooth) supports FTP, network printers, mobile hotspots, and more.
- 10.1-inch multi-touch display with customizable shortcuts.
