AMETEK 아메텍 DLM 600 1/2 랙 프로그래밍 가능 DC 파워서플라이 ☆ 가격문의
111,111원
AMETEK DLM 600 1/2 랙 프로그래밍 가능 DC 파워서플라이
AMETEK DLM 600 1/2 Rack Programmable DC Power Supplies
- Model: DLM 600
- Voltage: 5V - 300V
- Current: 2A - 75A
- Power: 375W - 600W
- Overview: 1/2 Rack Programmable DC Power Supplies
문의 010 7574 9841
평일 오전9시 ~ 오후6시 입니다. (공휴일은 통화불가합니다)
부재중일시 전화나 카톡 남겨주시면 업무시간때 체크후 피드백 드리겠습니다.
아메텍 ・ AMETEK
DLM 600
1/2 랙 프로그래밍 가능 DC 파워서플라이
DLM 600 1/2 Rack Programmable DC Power Supplies
The Sorensen DLM 600 series of DC programmable power supplies are designed to provide continuously variable DC output voltage and current for a broad range of applications in a compact 1U (1.75 inches) high, half-rack (8.5 inches) wide chassis.
With the use of Zero Voltage Switching (ZVS) technology, these supplies can achieve exceptionally low ripple and noise rivaling larger and more expensive linear power supplies.
In addition, the high efficiency and fast load transient response assure that the DLM 600 1/2 rack DC power supply is ideal for even the most demanding applications.
The DLM 600 variable DC power supply series is ideal for high-density multiple output rackmount requirements or low-profile benchtop applications. Output voltages from 0-5VDC to 0-300VDC and currents from 0-2A to 0-75A are available.
The cooling air intake is at the front and sides with exhaust at the rear and sides. Variable speed fans are controlled as a function of ambient air temperature and load, thus reducing acoustic noise, and increasing fan life. This allows programmable DC supplies to be stacked one directly on top of another without space in between, yielding maximum rackmount packing density and a wide operating temperature of 0-50° C. An optional rackmount kit is available to easily mount one- or two units side-by-side.
The front panel layout makes the DLM 600 DC power supply series easy to use. Voltage and current can be set from individual 10-turn potentiometer knobs. Control push buttons include power on, output on, local/remote, voltage/current preview, and overvoltage protection preview. Set point or actual voltage/ current values can be viewed on two 3-1/2-digit LED displays.
DLM 600 near-linear DC power supplies can be connected in series or parallel. All models automatically accept any standard single-phase input without manual setup.
Features and Benefits
- High Power Density
600 watts in 1U (1.75 inches) high, half rack (8.5 inches) wide; no top or bottom clearance spacing required.
- Near Linear Ripple & Noise
Ripple as low as 2.5mVrms, noise as low as 15mV p-p.
- Remote Control
- 16-bit programming through LXI-compliant Ethernet LAN / RS-232C (Option M130)
- 12-bit programming through IEEE-488.2 / RS-232C (Option M9G)
- Standard analog programming 0-5V, 0-10V, or 0-5kΩ.
- isolated analog programming (option)
- Pushbutton Preview
Overvoltage protection, voltage, and current preview buttons allow viewing these set points at any time with or without the output enabled.
- Active Down Programming
Standard internal circuitry to speed up response time to down programming changes.
- Universal AC Input
Easy leader/follower paralleling with active current sharing.
- Software
- IVI-com driver for M130 option
- Labwindows CVI driver for M9G option
- Labview driver for M9G option
- 5 Year Warranty
DLM 600 DLM 600 아메텍 아메텍 DLM 600 DLM 600 AMETEK AMETEK DLM 600
■ 제품 사양 (Specifications)
AMETEK 제품 데이터시트의 핵심 사양입니다.
- Half Rack Programmable DC Power Supply 5–300 V
- Voltage and Frequency 90-132 VAC or 180-264 VAC max, auto ranging, 47-63 Hz, single phase, 2-wire plus ground
- Current 11A maximum at 115VAC, 6A maximum at 230 VAC
- Connector IEC 320 with detachable line cord
- Power Factor 0.6, typical at full load; dependent on the impedance of the AC input.
- Line Regulation Voltage: 0.005% of V max + 2 mV
- Current: 0.01% of I max + 2 mA
- Load Regulation Voltage: 0.005% of V max + 2 mV
- Current: 0.02% of I max + 5 mA
- See table For 0-100% load variation, with constant nominal line voltage
- Transient Response 500 μs to steady-state output voltage (within 0.1% of Vmax) for 50-100% or 100-50% load change
- Operating Temperature 0°C to 50°C (no derating)
- Storage Temperature -40°C to 65°C
- Dimensions Width: 8.5” (216 mm)
- Weight 9.7 lbs. (4.4 kg)
- Shipping Weight 12.7 lbs. (5.8 kg)
- Dimensions in inches (millimeters) *80V, 150V and 300V models have two position terminal blocks for the output
- RS-232C Interface
- M9G IEEE-488.2 and RS-232C Interfaces
- M85 Multichannel Slave Interface
- M131 Multichannel Slave Interface (16 bit) (M130 Master ONLY)
- J1 Connector
- 1 ANALOG-CONTROL Input 14 EXTERNAL-OFF Input (+)
- 3 OVP Programming Input 16 OVP Resistance Programming Output
- 5 VOLTAGE-MODE Status Output 18 FAULT Status Output
- 7 Current Monitor Output 20 Voltage Resistance Programming Return
- 8 Voltage/Current Monitor Return 21 Voltage Resistance Programming Output
- 9 Voltage Programming Input 22 Current Resistance Programming Output
- 10 Current Programming Input 23 Current Resistance Programming Return
- 12 V/I/OVP Programming Return 25 OVP Status Output
본 사양은 제조사 공식 데이터시트의 핵심 항목을 정리한 것입니다. 전체 원문은 Lab 게시판 데이터시트를 참고하시고, 정확한 견적·재고는 굿맨시스템으로 문의 바랍니다.
