GW INSTEK 굿윌 인스텍 굿윌인스텍 APS-7050E – 리니어 AC 전원 공급 장치 (가격문의)
GW INSTEK 굿윌인스텍 APS-7050E – 리니어 AC 전원 공급 장치
GW Instek은 APS-7000 시리즈 프로그래머블 AC 전원의 경제 버전 APS-7000E 시리즈를 출시합니다. 2U 높이에서 APS-7050E의 최대 정격 출력은 500VA, 310Vrms, 4.2Arms이고 APS-7100E는 1000VA, 310Vrms, 8.4Arms입니다.
시리즈의 출력 주파수 범위는 45~500Hz입니다. 이 시리즈는 DC 전원 공급 장치, 소비자 전자 제품, 자동차 전자 제품 및 전자 부품의 테스트 및 개발에 이상적입니다.



문의 010 7574 9841
평일 오전9시 ~ 오후6시 입니다. (공휴일은 통화불가합니다)
부재중일시 전화나 카톡 남겨주시면 업무시간때 체크후 피드백 드리겠습니다.
GW INSTEK 굿윌인스텍 APS-7050E – 리니어 AC 전원 공급 장치
GOOD WILL INSTEK
APS-7000E Series — AC Power Sources

• APS-7000E Series
APS-7050E ・ APS-7100E
특징
- 4.3인치 TFT-LCD 디스플레이
- 출력 용량: APS-7050E(500VA, 310Vrms, 4.2/2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/4.2Arms)
- 88mm(2U) 케이스 높이만
- 측정 기능은 전압, 전류, 전력, 전류(피크), 주파수, 역률로 구성됩니다.
- 테스트 모드의 10 세트는 전력 과도 출력을 시뮬레이션합니다.
- 사용자가 10개의 설정을 저장할 수 있는 10개의 사전 설정 세트
Features
- 4.3 inch TFT-LCD Display
- Output Capacity: APS-7050E(500VA, 310Vrms, 4.2/ 2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/ 4.2Arms)
- Only 88mm(2U) case height
- Measurement function comprises Voltage, Current, Power, Current(peak), Frequency, Power Factor
- 10 sets of the Test mode simulate power transient output
- 10 sets of Preset allow users to store ten settings
설명
GW Instek은 APS-7000 시리즈 프로그래머블 AC 전원의 경제 버전 APS-7000E 시리즈를 출시합니다. 2U 높이에서 APS-7050E의 최대 정격 출력은 500VA, 310Vrms, 4.2Arms이고 APS-7100E는 1000VA, 310Vrms, 8.4Arms입니다.
시리즈의 출력 주파수 범위는 45~500Hz입니다. 이 시리즈는 DC 전원 공급 장치, 소비자 전자 제품, 자동차 전자 제품 및 전자 부품의 테스트 및 개발에 이상적입니다.
APS-7000E 시리즈는 6개의 측정 및 테스트 기능(Vrms, Irms, F, Ipk, W, PF)으로 구성되며 AC Power Meter와 유사한 사용자 인터페이스를 제공합니다. APS7000E 시리즈는 많은 전류 레벨을 전환하여 작은 전류 측정 분해능을 높임으로써 LED 산업 및 대기 모드 전력 소비 테스트에 이상적입니다. 10개의 사전 설정 세트를 통해 사용자는 10개의 설정을 저장할 수 있습니다.
APS-7000E 시리즈는 가전제품에서 흔히 볼 수 있는 라인 전압 변동 테스트 기준을 충족하기 위해 안정적인 AC 전원을 제공할 뿐만 아니라 특별하거나 비정상적인 전압 및 주파수 변동 요구를 충족하는 테스트 모드를 제공합니다.
테스트 모드의 10개 세트는 정전, 전압 상승 및 전압 하강을 시뮬레이션합니다. 도시 전력망의 과도 변화 파형을 시뮬레이션하는 APS7000E 시리즈는 비정상적인 전원에서 작동하는 전자 제품을 검증하는 데 적합합니다.
APS-7000E 시리즈는 APS-7000 시리즈의 이코노미 버전입니다. 통신 인터페이스와 더 큰 전압/주파수가 필요한 경우 APS-7000 시리즈를 참조하십시오.
Description
GW Instek launches the APS-7000E Series the economy version of the APS-7000 Series programmable AC power source. With the height of 2U, the maximum rated output for APS-7050E is 500VA, 310Vrms, 4.2Arms and APS-7100E is 1000VA, 310Vrms, 8.4Arms.
The output frequency range of the series is 45~500Hz. The series is ideal for the test and development of DC power supply devices, consumer electronics, automotive electronics and electronic components.
The APS-7000E Series comprises six measurement and test functions (Vrms, Irms, F, Ipk, W, PF), and provides user interface similar to that of AC Power Meter. The APS7000E Series, via switching many sets of current levels to increase small current measurement resolution, is ideal for the LED industry and standby mode power consumption test. Ten sets of Preset allow users to store ten settings.
To meet the test criteria of line voltage fluctuation often seen in consumer electronics, the APS-7000E Series not only provides a stable AC power source but also features the Test mode to satisfy special or abnormal voltage and frequency variation demands.
Ten sets of the Test mode simulate power outage, voltage rise, and voltage fall. The APS7000E Series that simulates waveforms of city power grid s transient changes is suitable for verifying electronics products operated under abnormal power source.
The APS-7000E Series is the economy version of the APS-7000 Series. If communications interface and larger voltage/frequency are required, please refer to the APS-7000 Series.





문의 010 7574 9841
평일 오전9시 ~ 오후6시 입니다. (공휴일은 통화불가합니다)
부재중일시 전화나 카톡 남겨주시면 업무시간때 체크후 피드백 드리겠습니다.
GW INSTEK 굿윌인스텍 APS-7050E – 리니어 AC 전원 공급 장치
GOOD WILL INSTEK
APS-7000E Series — AC Power Sources

• APS-7000E Series
APS-7050E ・ APS-7100E
특징
- 4.3인치 TFT-LCD 디스플레이
- 출력 용량: APS-7050E(500VA, 310Vrms, 4.2/2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/4.2Arms)
- 88mm(2U) 케이스 높이만
- 측정 기능은 전압, 전류, 전력, 전류(피크), 주파수, 역률로 구성됩니다.
- 테스트 모드의 10 세트는 전력 과도 출력을 시뮬레이션합니다.
- 사용자가 10개의 설정을 저장할 수 있는 10개의 사전 설정 세트
Features
- 4.3 inch TFT-LCD Display
- Output Capacity: APS-7050E(500VA, 310Vrms, 4.2/ 2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/ 4.2Arms)
- Only 88mm(2U) case height
- Measurement function comprises Voltage, Current, Power, Current(peak), Frequency, Power Factor
- 10 sets of the Test mode simulate power transient output
- 10 sets of Preset allow users to store ten settings
설명
GW Instek은 APS-7000 시리즈 프로그래머블 AC 전원의 경제 버전 APS-7000E 시리즈를 출시합니다. 2U 높이에서 APS-7050E의 최대 정격 출력은 500VA, 310Vrms, 4.2Arms이고 APS-7100E는 1000VA, 310Vrms, 8.4Arms입니다.
시리즈의 출력 주파수 범위는 45~500Hz입니다. 이 시리즈는 DC 전원 공급 장치, 소비자 전자 제품, 자동차 전자 제품 및 전자 부품의 테스트 및 개발에 이상적입니다.
APS-7000E 시리즈는 6개의 측정 및 테스트 기능(Vrms, Irms, F, Ipk, W, PF)으로 구성되며 AC Power Meter와 유사한 사용자 인터페이스를 제공합니다. APS7000E 시리즈는 많은 전류 레벨을 전환하여 작은 전류 측정 분해능을 높임으로써 LED 산업 및 대기 모드 전력 소비 테스트에 이상적입니다. 10개의 사전 설정 세트를 통해 사용자는 10개의 설정을 저장할 수 있습니다.
APS-7000E 시리즈는 가전제품에서 흔히 볼 수 있는 라인 전압 변동 테스트 기준을 충족하기 위해 안정적인 AC 전원을 제공할 뿐만 아니라 특별하거나 비정상적인 전압 및 주파수 변동 요구를 충족하는 테스트 모드를 제공합니다.
테스트 모드의 10개 세트는 정전, 전압 상승 및 전압 하강을 시뮬레이션합니다. 도시 전력망의 과도 변화 파형을 시뮬레이션하는 APS7000E 시리즈는 비정상적인 전원에서 작동하는 전자 제품을 검증하는 데 적합합니다.
APS-7000E 시리즈는 APS-7000 시리즈의 이코노미 버전입니다. 통신 인터페이스와 더 큰 전압/주파수가 필요한 경우 APS-7000 시리즈를 참조하십시오.
Description
GW Instek launches the APS-7000E Series the economy version of the APS-7000 Series programmable AC power source. With the height of 2U, the maximum rated output for APS-7050E is 500VA, 310Vrms, 4.2Arms and APS-7100E is 1000VA, 310Vrms, 8.4Arms.
The output frequency range of the series is 45~500Hz. The series is ideal for the test and development of DC power supply devices, consumer electronics, automotive electronics and electronic components.
The APS-7000E Series comprises six measurement and test functions (Vrms, Irms, F, Ipk, W, PF), and provides user interface similar to that of AC Power Meter. The APS7000E Series, via switching many sets of current levels to increase small current measurement resolution, is ideal for the LED industry and standby mode power consumption test. Ten sets of Preset allow users to store ten settings.
To meet the test criteria of line voltage fluctuation often seen in consumer electronics, the APS-7000E Series not only provides a stable AC power source but also features the Test mode to satisfy special or abnormal voltage and frequency variation demands.
Ten sets of the Test mode simulate power outage, voltage rise, and voltage fall. The APS7000E Series that simulates waveforms of city power grid s transient changes is suitable for verifying electronics products operated under abnormal power source.
The APS-7000E Series is the economy version of the APS-7000 Series. If communications interface and larger voltage/frequency are required, please refer to the APS-7000 Series.
